Polyester Filter

POLYESTER FILTER

The Long polyester filter media is safe and easy to handle and does not break down in use. Suitable for uses where fiberglass is not indicated, such as food processing and medical facilities. Fibers are held together with resin that is flame retardant and moisture resistant.

Media consisting of 100% polyester bonded fibers is formed into an interlocking pattern that traps dust and lint, while minimizing face surface loading. Polyester media fibers won’t break off and flow into air stream.

Used to replace fiberglass filters where minimal downstream contamination is required. Filters have metal support on both sides and a heavy cardboard frame. For all heating ventilating, andair-conditioning applications.

Đặc điểm

Thông số kỹ thuật

Kích thước

Các tính năng khác

Đặc điểm

PURPOSE

This type of filter serves as the first gate of the air filtration system and it is mainly used to fulter outside air. Polyester Filter is disposable, so multiple usages is not recommended.
Polyester Filter is suitable for all kinds industrial manifactures, such as contamination prevention, HVAC system, waste treatment and contaminated process air.
Polyester Filter is also commonly used in pharmaceutical manufacture and food processing due its ability to filter contamination air.

CUSTOMIZED MADE POLYSTER

Fire-retarded filter and anti-virus filter can also be made with imported Polyester fiber and be processed and packed in local factory.

SIZES:

In rolls
In pieces

Thông số kỹ thuật

*Other sizes available: Consult Factory for sizes and performance data*

Kích thước

SPECIFICATION

Model	Nominal	Depth	Wind Velocity	Resistance		Efficiency
Model	W*L	MM	V m/s	Initial (mmAq)	End (mmAq)	%
ATV-P2FP-50MA00005N-001	1M*50M	5	2.5	3.5	15	70
ATV-P2FP-30MA00010N-001	1M*30M	10	2.5	4.7	20	80
ATV-P2FP-20MA00020N-001	1M*20M	20	2.0	6.5	20	85
ATV-P2FP-20MA00025N-001	1M*20M	25	2.0	7.0	20	90
ATV-P2FP-50MC000005-001	1.2M*50M	5	2.5	3.5	15	70
ATV-P2FP-30MC000010-001	1.2M*30M	10	2.5	4.7	20	80
ATV-P2FP-20MC000020-001	1.2M*20M	20	2.5	6.5	20	85
ATV-P2FP-20MC00025N-001	1.2M*20M	25	2.0	7.0	20	90
ATV-P2FP-20MK00020N-001	2M*20M	20	1.5	6	24.5	93
