Safety cabinet type air isolation system

It is an open operation type system that prevents cross contamination as much as possible for industrialization of regenerative medicine.

Đặc điểm

Thông số kỹ thuật

Kích thước

Các tính năng khác

Đặc điểm

Minimize decontamination area during changeover.
If the opening operation of the culture vessel is restricted within the air isolation system (AIS), theoretical aerosol diffusion is only within AIS.
*Since there are no walls or workbenches in AIS, there is no contact part in terms of operation.
We will create a confinement area with the airflow of the secondary barrier grade A in the workroom of the safety barriers and isolators that are the primary barriers and localize the range of the opening operation of the culture vessel.
If AIS is added and double containment has been established, the AIS in the grade A safety cabinet will be a doubly isolated grade A sterile, containment area.
You can discard used pipettes etc in AIS. Air isolation system (AIS) is a registered trademark of Nippon AirTech.
* Patent pending

Thông số kỹ thuật

Safety cabinet part specification:

Model	BHC-1307ⅡA2-AIS
Dust collect efficiency	More than 99.99% at 0.3µm
Filter	Supply/Exhaust: HEPA filter (scan test item)
Processing air volume	Supply: Abt 14.4m³/phút Front opening size 200 mm Exhaust: abt 8.6m³/min Front opening size 200 mm
Wind speed in work room	Supply: Abt 0.33m/sec*Front opening size 200 mm
Front suction wind speed/td>	Supply: abt 0.55m/sec *Front opening size 200 mm
Power supply	AC100V　1φ　50/60Hz
Power cónumption	Abt 600W (abt 850VA), Blower + Lighting operation, outlet capacity not included
Blower	LNF‐10×1
LED lighting	11W×3
Sterilizing lamp	10W×2
Weight	Abt 450kg
Average illuminance	Abt 1000Lux
Other	Built-in USP
Structure	Body: Powder coated steel, work room: stainless steel
Option	Exhaust Filter Differential Pressure Gauge, Vacuum Pump or Aspirator, Autopipette, Differential Pressure Switch HEPA Filter Clogging Warning (Display with Buzzer)

Air isolation system (AIS)

Dust collect efficiency	More than 99.99% at 0.3µm
Filter	Main filter for AIS: HEPA filter (scan test item)
Processing air volume	Supply: 2.2m³/min Exhaust: 7.3m³/min * Perimeter opening size 220 mm
Alarm	In the following cases, alarm is issued by buzzer and display. When a fan error occurs. Front inflow wind speed and air supply wind speed abnormality When the front opening of the shutter opening (200 mm or 250 mm) is different from the opening height used. When other alarm occurs. (For details, refer to the instruction manual)
